Mobile Antenna suitable for ICOM IC-A120E or ICOM IC-A110.
This antenna may be mounted on gutter fittings, bullbar mounts or mirror installations.
Picture for illustration purposes only – coaxial cable is supplied with a separate UHF connector which may be terminated once the cable has been fed through the vehicle firewall. Some tools will be required for termination.
The BMV 118137 Series antenna area a range of full band, omni-directional, unity gain, antennas designed for heavy
duty applications including the VHF aeronautical band of 118-137MHz.
The full band monocone design lends itself to excellent pattern consistency over a wider bandwidth than
conventional ground plane antennas, and a lower angle of radiation.
This model is constructed of stainless steel mount tube and radiator enclosed in an ABS radome, with
full band covrage offering a “no tune” solution. The antenna is also DC grounded, offering some lightning
protection and a reduction of precipitation static noise.
